Like the #5LP Housekeeper, the DB-2LP is a low profile model that has all the features of the full size DB-2.
| Working Height | 69 |
| Overall Length | 22.5′ |
| Overall Width | 84″ |
| Weight | 6800lbs (empty) |
| Throat | 69″ |
| Capacity | 165 cu. ft. |
| Tires | 12.5L x 16 |
| Tires (Tandem Optional) | 9.5L x 15 |
| Required PTO Horsepower | 60 HP |
| Hydraulic Oil | AW-68 |
| PTO Hydraulic Pump | 22 gpm |
| Oil Reservoir Capacity | 30 gal |
Attach optional equipment to your Lewis Brothers products to make jobs easier, reduce work time, and ensure thorough cleaning. Replacement parts are available upon request from your local dealer.
For more information about ordering replacement parts please contact us at 912.367.4651
Solid bars are available on model’s #2, #3, #3.5, #4, #DB-1 & #DB-4. By adding the solid bars, the operator can convert from de-caking to total cleanout in a short time.
The tandem axle is available on model’s #3.5, #4, #5, #5LP, #DB-2, #DB-2LP, #DB4 and the Spreader Body. The tandem axle provides a wider base and can absorb rough terrain.
